Description
| Rim (inch) | Size | Service Index | Tread Depth (32nd) | Standard Rim | Section Width (inch) | Overall Diameter (inch) | Max. Load (lbs) | Max. Air Pressure (psi) | UTQG | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 13″ | 165/65R13 | 77T | 9.4 | 5.0J | 6.7 | 21.4 | 908 | 44 | 500 | A | A |
| 175/70R13 | 82T | 9.4 | 5.0B | 7 | 22.7 | 1047 | 44 | 500 | A | A | |
| 185/70R13 | 86T | 9.4 | 5.5J | 7.4 | 23.2 | 1168 | 44 | 500 | A | A | |
| 155/80R13 | 79T | 9.4 | 4.5B | 6.2 | 22.8 | 963 | 44 | 500 | A | A | |
| 165/80R13 | 83T | 9.4 | 4.5J | 6.5 | 23.4 | 1074 | 44 | 500 | A | A | |
| 14″ | 165/55R14 | 72V | 9.4 | 5.0J | 6.7 | 21.2 | 783 | 44 | 500 | A | A |
| 185/60R14 | 82H | 9.4 | 5.5J | 7.4 | 22.8 | 1047 | 44 | 500 | A | A | |
| 195/60R14 | 86H | 9.8 | 6.0J | 7.9 | 23.2 | 1168 | 44 | 500 | A | A | |
| 175/65R14 | 82H | 9.4 | 5.0J | 7 | 23 | 1047 | 44 | 500 | A | A | |
| 185/65R14 | 86H | 9.4 | 5.5J | 7.4 | 23.5 | 1168 | 44 | 500 | A | A | |
| 175/70R14 | 84T | 9.4 | 5.0J | 7 | 23.7 | 1102 | 44 | 500 | A | A | |
| 185/70R14 | 88T | 9.4 | 5.5J | 7.4 | 24.3 | 1235 | 44 | 500 | A | A | |
| 195/70R14 | 91T | 9.8 | 6.0J | 7.9 | 24.8 | 1356 | 44 | 500 | A | A | |
| 205/70R14 | 95T | 9.8 | 6.0J | 8.2 | 25.4 | 1521 | 44 | 500 | A | A | |
| 15″ | 165/50R15 | 72V | 9.4 | 5.0J | 6.7 | 21.5 | 783 | 44 | 500 | A | A |
| 195/50R15 | 82V | 9.8 | 6.0J | 7.9 | 22.7 | 1047 | 44 | 500 | A | A | |
| 185/55R15 | 82V | 9.4 | 6.0J | 7.6 | 23 | 1047 | 44 | 500 | A | A | |
| 195/55R15 | 85V | 9.8 | 6.0J | 7.9 | 23.4 | 1135 | 44 | 500 | A | A | |
| 185/60R15 | 84H | 9.4 | 5.5J | 7.4 | 23.7 | 1102 | 44 | 500 | A | A | |
| 195/60R15 | 88H | 9.8 | 6.0J | 7.9 | 24.2 | 1235 | 44 | 500 | A | A | |
| 205/60R15 | 91H | 9.8 | 6.0J | 8.2 | 24.7 | 1356 | 44 | 500 | A | A | |
| 215/60R15 | 94H | 9.8 | 6.5J | 8.7 | 25.2 | 1477 | 44 | 500 | A | A | |
| 175/65R15 | 84H | 9.4 | 5.0J | 7 | 24 | 1102 | 44 | 500 | A | A | |
| 185/65R15 | 88H | 9.4 | 5.5J | 7.4 | 24.4 | 1235 | 44 | 500 | A | A | |
| 195/65R15 | 91H | 9.8 | 6.0J | 7.9 | 25 | 1356 | 44 | 500 | A | A | |
| 205/65R15 | 94H | 9.8 | 6.0J | 8.2 | 25.5 | 1477 | 44 | 500 | A | A | |
| 205/70R15 | 96H | 9.8 | 6.0J | 8.2 | 26.3 | 1565 | 44 | 500 | A | A | |
| 215/70R15 | 98H | 9.8 | 6.5J | 8.7 | 26.9 | 1653 | 44 | 500 | A | A | |
| 16″ | 195/50R16 | 84V | 9.8 | 6.0J | 8.3 | 23.7 | 1102 | 44 | 500 | A | A |
| 205/50R16 | 87V | 9.8 | 6.5J | 8.4 | 24.1 | 1201 | 44 | 500 | A | A | |
| 185/55R16 | 83V | 9.4 | 6.0J | 7.6 | 24 | 1074 | 44 | 500 | A | A | |
| 195/55R16 | 87V | 9.8 | 6.0J | 7.9 | 24.4 | 1201 | 44 | 500 | A | A | |
| 205/55R16 | 91V | 9.8 | 6.5J | 8.4 | 24.9 | 1356 | 44 | 500 | A | A | |
| 215/55R16 | 93V | 9.8 | 7.0J | 8.9 | 25.3 | 1433 | 44 | 500 | A | A | |
| 225/55R16 | 95V | 9.8 | 7.0J | 9.2 | 25.7 | 1521 | 44 | 500 | A | A | |
| 185/60R16 | 86H | 9.4 | 5.5J | 7.4 | 24.7 | 1168 | 44 | 500 | A | A | |
| 205/60R16 | 92H | 9.8 | 6.0J | 8.2 | 25.7 | 1389 | 44 | 500 | A | A | |
| 215/60R16 | 95H | 9.8 | 6.5J | 8.7 | 26.1 | 1521 | 44 | 500 | A | A | |
| 225/60R16 | 98H | 9.8 | 6.5J | 9 | 26.6 | 1653 | 44 | 500 | A | A | |
| 235/60R16 | 100H | 9.8 | 7.0J | 9.4 | 27.1 | 1764 | 44 | 500 | A | A | |
| 205/65R16 | 95H | 9.8 | 6.0J | 8.2 | 26.5 | 1521 | 44 | 500 | A | A | |
| 215/65R16 | 98H | 9.8 | 6.5J | 8.7 | 27 | 1653 | 44 | 500 | A | A | |
| 225/65R16 | 100H | 9.8 | 6.5J | 9 | 27.5 | 1764 | 44 | 500 | A | A | |
| 235/65R16 | 103H | 9.8 | 7.0J | 9.4 | 28 | 1929 | 44 | 500 | A | A | |
| 17″ | 225/50R17 | 94V | 9.8 | 7.0J | 9.2 | 25.9 | 1477 | 44 | 500 | A | A |
| 215/55R17 | 94V | 9.8 | 7.0J | 8.9 | 26.3 | 1477 | 44 | 500 | A | A | |
| 225/55R17 | 97H | 9.8 | 7.0J | 9.2 | 26.8 | 1609 | 44 | 500 | A | A | |
| 235/55R17 | 99H | 9.8 | 7.5J | 9.6 | 27.2 | 1709 | 44 | 500 | A | A | |
| 225/60R17 | 99H | 9.8 | 6.5J | 9 | 27.6 | 1709 | 44 | 500 | A | A | |
| 225/65R17 | 102T | 9.8 | 6.5J | 9 | 28.5 | 1874 | 44 | 500 | A | A | |
| 235/65R17 | 104H | 9.8 | 7.0J | 9.4 | 29.1 | 1984 | 44 | 500 | A | A | |
| 18″ | 225/40R18 XL | 92V | 9.8 | 8.0J | 9.1 | 25.1 | 1389 | 51 | 500 | A | A |
| 225/45R18 XL | 95V | 9.8 | 7.5J | 8.9 | 25.9 | 1521 | 51 | 500 | A | A | |
| 235/45R18 XL | 98V | 9.8 | 8.0J | 9.3 | 26.3 | 1653 | 51 | 500 | A | A | |
| 245/45R18 XL | 100V | 9.8 | 8.0J | 9.6 | 26.7 | 1764 | 51 | 500 | A | A | |
| 225/50R18 | 95V | 9.8 | 7.0J | 9.2 | 26.9 | 1521 | 44 | 500 | A | A | |
| 235/50R18 | 97V | 9.8 | 7.5J | 9.6 | 27.3 | 1609 | 44 | 500 | A | A | |
| 235/65R18 | 106T | 9.8 | 7.0J | 9.4 | 30 | 2094 | 44 | 500 | A | A | |
* We reserve the rights of final interpretation and modification
