Description
| Rim (inch) |
Size | LR/PR | Service Index |
Tread Depth (32nd) |
Standard Rim |
Section Width (inch) |
Overall Diameter (inch) |
Max. Load (lbs) |
Max. Air Pressure (psi) |
|---|---|---|---|---|---|---|---|---|---|
| 16″ | LT225/75R16 | E/10PR | 115/112Q | 14.5 | 6.0J | 8.8 | 29.3 | 2680/2470 | 80 |
| LT245/75R16 | E/10PR | 120/116Q | 14.5 | 7.0J | 9.8 | 30.5 | 3042/2778 | 80 | |
| LT265/75R16 | E/10PR | 123/120Q | 14.5 | 7.5J | 10.5 | 31.7 | 3415/3085 | 80 | |
| LT215/85R16 | E/10PR | 115/112Q | 14.5 | 6.0J | 8.5 | 30.4 | 2680/2470 | 80 | |
| LT235/85R16 | E/10PR | 120/116Q | 14.5 | 6.5J | 9.3 | 31.7 | 3042/2778 | 80 | |
| 17″ | LT245/70R17 | E/10PR | 119/116Q | 14.5 | 7.0J | 9.8 | 30.6 | 3000/2755 | 80 |
| LT265/70R17 | E/10PR | 121/118Q | 14.5 | 8.0J | 10.7 | 31.7 | 3195/2910 | 80 | |
| LT245/75R17 | E/10PR | 121/118Q | 14.5 | 7.0J | 9.8 | 31.5 | 3195/2910 | 80 | |
| LT235/80R17 | E/10PR | 120/117Q | 14.5 | 6.5J | 9.3 | 31.8 | 3085/2835 | 80 | |
| 18″ | LT265/70R18 | E/10PR | 124/121Q | 14.5 | 8.0J | 10.7 | 32.6 | 3525/3195 | 80 |
| LT275/70R18 | E/10PR | 125/122Q | 14.5 | 8.0J | 11 | 33.2 | 3640/3305 | 80 |
* We reserve the rights of final interpretation and modification
