Description
| Size | LR/PR | Tread Depth (32ND) |
Service Index |
Standard Rim |
Overall Diameter (inch) |
Section Width (inch) |
Max. Load Capacity at Cold Inflation Pressure | Revs per Mile |
Static Loaded Radius (inch) |
|||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Single | Dual | |||||||||||
| (LBS) | (PSI) | (LBS) | (PSI) | |||||||||
| 11R22.5 | G/14 | 12 | 144/142M | 8.25 | 41.5 | 11.0 | 6175 | 105 | 5840 | 105 | 500 | 19.3 |
| 295/75R22.5 | G/14 | 12 | 144/141M | 9.00 | 39.9 | 11.7 | 6175 | 110 | 5675 | 110 | 521 | 18.6 |
* We reserve the rights of final interpretation and modification
