Description
| Item Code | Tire Size | STD. Rim | Tread Depth | Section Width | Overall Dia. | Max. Load | Max. Pressure | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| In. | mm | 1/32 In. | mm | mm | Kg | lbs. | KPa | PSI | |||
| 13 In. | |||||||||||
| FR1000P1301 | 155/70R13 | 75T | 4.5J | 8.0 | 10.1 | 157 | 548 | 387 | 853 | 300 | 44 |
| FR1000P1302 | 155/80R13 | 79T | 4.5J | 8.0 | 10.1 | 157 | 578 | 437 | 963 | 300 | 44 |
| FR1000P1303 | 165/65R13 | 77T | 5.0J | 8.0 | 10.1 | 170 | 544 | 412 | 908 | 300 | 44 |
| FR1000P1304 | 165/70R13 | 79T | 5.0J | 8.0 | 10.1 | 170 | 562 | 437 | 963 | 300 | 44 |
| FR1000P1305 | 175/70R13 | 82T | 5.0J | 8.0 | 10.1 | 177 | 576 | 475 | 1047 | 300 | 44 |
| 14 In. | |||||||||||
| FR1000P1401 | 175/65R14 | 82H | 5.0J | 8.0 | 10.1 | 177 | 584 | 475 | 1047 | 300 | 44 |
| FR1000P1402 | 175/70R14 | 84H | 5.0J | 7.8 | 9.8 | 177 | 602 | 500 | 1102 | 300 | 44 |
| FR1000P1403 | 185/60R14 | 82H | 5.5J | 8.0 | 10.1 | 189 | 578 | 475 | 1047 | 300 | 44 |
| FR1000P1404 | 185/65R14 | 86H | 5.5J | 8.0 | 10.1 | 189 | 596 | 530 | 1168 | 300 | 44 |
| FR1000P1405 | 185/70R14 | 88H | 5.5J | 8.0 | 10.1 | 189 | 616 | 560 | 1235 | 300 | 44 |
| 16 In. | |||||||||||
| FR1000P1601 | 205/55R16 | 91V | 6.5J | 8.0 | 10.1 | 214 | 632 | 615 | 1356 | 300 | 44 |
| FR1000P1602 | 205/55R16 | 94V/XL | 6.5J | 8.0 | 10.1 | 214 | 632 | 670 | 1477 | 340 | 49 |
| FR1000P1603 | 205/55R16 | 91W | 6.5J | 8.0 | 10.1 | 214 | 632 | 615 | 1356 | 300 | 44 |
| FR1000P1604 | 205/55R16 | 94W/XL | 6.5J | 8.0 | 10.1 | 214 | 632 | 670 | 1477 | 340 | 49 |
